New Holland E385 Crawler Excavator Workshop Manual 604.13.679

New Holland E385 Crawler Excavator Workshop Manual 604.13.679
=============================================================

TECHNICAL SPECIFICATIONS:
----------------------------------------
Size: 21.24 MB
Pages: 700
Format: PDF
Language: English
Brand: NEW HOLLAND

CONTENTS (Table of Contents):
----------------------------------------
E385 IN-1
TO THE READER
• This manual is written for an experienced techni-
cian to provide technical information needed tomaintain and repair this machine.
- Be sure to thoroughly read this manual for correct
information concerning the service procedures.- If you have any questions or comments, or if you
NEW HOLLAND KOBELCO
ADDITIONAL REFERENCES
 Please refer to the materials listed below in addition
to this service manual:
-Operation and Maintenance Instruction Manual
-Parts Catalog
WORKSHOP MANUAL COMPOSITION
- The “Operational Performance Test” part includes
the information needed to carry out the machineoperational performance test.
- The “Troubleshooting” part includes the technical
information needed for troubleshooting and mal-function detection.
- The “Repair Instruction” part includes information
-“Safety Precautions”
-“Operational Principle”
-“Operational Performance Test”
-“Troubleshouting”
-“Repair Instructions”
- The “Safety Precaution” part includes the recom-
- The “Operational Principle” part includes the techni-
cal information concerning the operation of maindevices and systems.
Group 1 Hydraulic Pump Assy .............................................................. T3-1
Group 4 Swing Device .......................................................................... T3-4
Group 2 Standard Performances ............................................................ T4-2
Group 3 Test Procedures ....................................................................... T4-3
TROUBLESHOOTING
Group 1 Mechatro Control ..................................................................... T5-1
Group 2 Hydraulic System .................................................................... T5-2
Group 3 Electrical System .................................................................... T5-3
Group 2 Component Layout ................................................................... T1-2
Group 1 Mechatro Control System ........................................................ T2-1
Group 2 Mechatro Controller ................................................................. T2-2
Group 3 Hydraulic System .................................................................... T2-3
Group 1 Precautions for Disassembly and Assembly ......................... W1-1
Group 2 Tightening Torque .................................................................. W1-2
Group 2 Air Conditioner ...................................................................... W2-2
Group 3 Counterweight ....................................................................... W2-3
Group 4 Main Frame ........................................................................... W2-4
Group 5 Pump Device ........................................................................ W2-5
Group 6 Control Valv e ........................................................................ W2-6
Group 7 Swing Device ........................................................................ W2-7
Group 9 Solenoid Valv e Unit ............................................................... W2-9
Group 1 Swing Bearing ....................................................................... W3-1
Group 2 Travel Device ........................................................................ W3-2
Group 3 Swivel Joint .......................................................................... W3-3
Group 4 Track Adjuster ....................................................................... W3-4
Group 6 Upper and Lower Roller ......................................................... W3-6
Group 1 Front Attachment .................................................................. W4-1
ENGINE
Troubleshooting
Print No. 604.13.654
Workshop
"WORKSHOP MANUAL 4HK1-6HK1 ISUZU ENGINE”Print No. 604.13.649
REPAIR INSTRUCTIONS

PLEASE NOTE:
----------------------------------------
This is a digital manual - no physical copy will be shipped.
The manual is available for immediate download after purchase.
