New Holland EH35 Compact Excavator Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
•
Service Manual:
674 pages
Specifications:
•
Brand:
New Holland
•
Model:
EH35
•
Type:
Excavator
•
Manuals:
Service Manual
•
Publication Numbers:
6-75740NA
•
Language:
English
•
Format:
PDF

Description
Table of contents
Specification
Maintenance
System
Disassembly
Troubleshooting
Engine
Miscellaneous
All repair and maintenance work listed in this manual must be carried out only by qualified personnel, strictly complying with the instructions given, and using, whenever possible, the special tools.
Thoroughly read and understand this Service manual and the Operators Manual before operating any repair or servicing.
For easy references the manual is breakdown in several chapter with an easy to follow instruction for repairing guidance of the different part of the Excavator.
All information contained in this New Holland Manual is updated
Engine Model
3TNE82A-YBD
Type
Vertical, 4-cycle water-cooled diesel engine
No. of cylinders – Bore X Stroke
3 – 82mm (3.23 in) X 84 mm (3.31 in)
Total displacement
1.33 liter (81.2 cuin)
Compression ratio
18
Rated output
24 PS (17.7 kW) at 2400 rpm
Maximum torque
8.1 ~ 8.5 kgfm (58.6 ~ 61.5 lbfft) at 1500 rpm
Low idling
1200 25 rpm
High idling
2590 25 rpm
Fuel consumption rate
Less than 175 g / PSh
Allowable tilting angles
Back and forth, left and right 25 (momentary 30)
Rotating direction
Counterclockwise as seen from flywheel side
Firing order
1-3-2-1
