Mack ASET-AI AMI (IEGR) Engine Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
Service Manual:
494 pages
Specifications:
Brand:
Mack
Model:
ASET AI/AMI
Type:
Engines with Exhaust Gas Recirculation (EGR)
Manuals:
Service Manual
Publication Numbers:
5-110 (October 2006)
Language:
English
Format:
PDF

Description
Table of Contents
GROUP
0
00 — GENERAL DATA
GROUP
1
00 — CHASSIS
GROUP
2
00 — ENGINE
GROUP
3
00 — CLUTCH, TRANSMISSION, TRANSFER CASE AND PTO
GROUP
4
00 — STEERING, AXLES, WHEELS AND TIRES, DRIVELINE
GROUP
5
00 — BRAKES, AUXILIARY SYSTEMS
GROUP
6
00 — CAB, TRUCK BODY
GROUP
7
00 — ELECTRICAL
This publication is intended to provide technicians with a working knowledge of the new ASET AI/AMI diesel engines with internal exhaust gas recirculation. MACK offers a similar engine to
AI/AMI which is more suited to linehaul applications called the AC. The AC engine is a cooled exhaust gas recirculation engine. For service and overhaul procedures for the AC engine, refer to the 5-111 ASET AC Engine Service Manual. ASET is an acronym meaning Application Specific Engine Technology.
The ASET AI/AMI engine design is based on the E-Tech left-side redesign (LSR) with its plate-type oil cooler and oil filter mounting  arrangement. In addition, a new Centri-Max
ULTRA or ULTRA PLUS centrifugal oil filter assembly having a redesigned cover housing with an integral oil fill tube, is incorporated in the design. The rear left-side mounting location of the engine electronic control unit (EECU) on the one-piece inlet manifold is retained for the engine
