Komatsu WA65-5, WA70-5, WA80-5 Wheel Loader Service Manual Workshop Guide
Komatsu WA65-5, WA70-5, WA80-5 Wheel Loader Service Manual Workshop Guide
Regular price
$57.00 USD
Regular price
Sale price
$57.00 USD
Taxes included.
Shipping calculated at checkout.
Quantity
.
In Stock
Couldn't load pickup availability
Format : PDF
SUPPLIED AS DOWNLOADABLE LINK
Manual Included:
Shop Manual:
306 pages
Specifications:
Brand:
Komatsu
Model:
WA65-5, WA70-5, WA80-5
Type:
Loader
Serial Number:
H50051 and up
Manuals:
Shop Manual
Publication Number:
VEBM250100
Language:
English
Format:
PDF
Description
Table of Contents
00 SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .00-1
01 GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .01-1
10 STRUCTURE AND FUNCTION . . . . . . . . . . . . . . . . . . . . . .10-1
20 TESTING AND ADJUSTING . . . . . . . . . . . . . . . . . . . . . . . .20-1
30 DISASSEMBLY AND ASSEMBLY . . . . . . . . . . . . . . . . . . .30-1
90 OTHERS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90-1
Manual Extract Regular maintenance Air Conditioning :
Check the air-conditioning system twice a year, in spring and autumn.
The air conditioning system must be switched on at least once a month for a brief time (approx. 10 min) so that the compressor is lubricated.
The following maintenance work must be carried out at the beginning, middle and end of a cooling period:
Check V-belt tension and compressor fastening.
1. Compressor
2. Fixing screw
3. Cover for Tension Pulley
Check coolant level, See chapter 10 STRUCTURE AND FUNCTION "Checking coolant level" on page 10-84.
NOTE
The coolant must flow through the filter dryer's inspection glass free of bubbles with the engine running and air conditioner at maximum output (max. blower setting, top idling speed, setting "cold").
Clean the condenser
