Komatsu WA40-1 Wheel Loader Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
Shop Manual:
345 pages
Specifications:
Brand:
Komatsu
Model:
WA40-1
Type:
Loader
Serial Number:
1001 and up
Manuals:
Shop Manual
Publication Number:
SEBM03630101
Language:
English
Format:
PDF

Description
Table of Contents
General
Engine
Torque Converter
Power Train
Steering System
Brake System
Working Equipment
Electric and Electronic System
Others
Manual Extract REMOVAL OF RADIATOR ASSEMBLY:
1. Loosen drain valve (1) and drain cooling water.
* If the coolant contains antifreeze, dispose of it correctly.
2. Open operator's seat assembly, and set safety rod securely in position.
3. Remove radiator top cover.
4. Disconnect hose (2) between radiator and sub-tank.
5. Remove radiator inlet hose.
6. Disconnect radiator outlet hose
7. Remove fan guard
8. Remove top and bottom shrouds
9. Remove 4 mounting nuts, then remove radiator assembly
