Komatsu WA380-3 Wheel Loader Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
Shop Manual:
808 pages, 592 pages, 970 pages
Specifications:
Brand:
Komatsu
Model:
WA380-3
Type:
Wheel Loader
Serial Numbers:
50001 and up
16001 and up
10001 and up
WA380H20051 and up
Manuals:
Shop Manual
Publication Number:
SEBM006105, SMEW3800T0, SMEW380000 and VEBM460104
Language:
English
Format:
PDF

Description
Table of Contents
01 GENERAL………………………………………………………………. 01-1
10 STRUCTURE AND FUNCTION………………………………… 10-1
20 TESTING AND ADJUSTING…………………………………….. 20-1
30 DISASSEMBLY AND ASSEMBLY…………………………….. 30-1
40 MAINTENANCE STANDARD……………………………………. 40-1
This shop manual mainly contains the necessary technical information for operations performed in a service workshop. For ease of understanding, the manual is divided into the following chapters; these chapters are further divided into the each main group of components
STRUCTURE AND FUNCTION
This section explains the structure and function of each component. It serves not only to give an understanding of the structure, but also serves as reference material for troubleshooting.
TESTING AND ADJUSTING
This section explains checks to be made before and after performing repairs, as well as adjustments to be made at completion of the checks and repairs.
Troubleshooting charts correlating "Problems" to "Causes" are also included in this section.
DISASSEMBLY AND ASSEMBLY
This section explains the order to be followed when removing, installing, disassembling or assembling each component, as well as precautions to be taken for these operations.
MAINTENANCE STANDARD
This section gives the judgement standards when inspecting disassembled parts.
