Komatsu W170-2 Wheel Loader Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
Shop Manual:
526 pages
Specifications:
Brand:
Komatsu
Model:
W170-2
Type:
Loader
Serial Number:
60001 and up
Manuals:
Shop Manual
Publication Number:
SEBM0384C01
Language:
English
Format:
PDF

Description
Table of Contents
General
Engine
Power Train
Steering System
Air System
Hydraulic System
Work Equipment
Others
Manual Extract:
DISASSEMBLY OF TRANSFER DRIVE
1. Caliper, support assembly Remove mounting bolt of support, then remove caliper and support assembly ( 1).
2. Yoke, disc plate
Remove mounting nut (2) of yoke, then remove yoke and parking brake disc assembly (3).
3. Disc support
Remove mounting bolt of disc support, then remove disc support (4).
4. Cover
Remove mounting bolt, then remove cover (5).
5. Shaft
Using a press, remove shaft (7) and bearing (8) from housing (6).
6. Disc plate
Remove disc plate (3) from yoke.
7. Bearing cup
Remove bearing cup (9) from housing (6).
