Komatsu W120-3 Wheel Loader Service Manual Workshop Guide
Komatsu W120-3 Wheel Loader Service Manual Workshop Guide
Regular price
$58.50 USD
Regular price
Sale price
$58.50 USD
Taxes included.
Shipping calculated at checkout.
Quantity
.
In Stock
Couldn't load pickup availability
Format : PDF
SUPPLIED AS DOWNLOADABLE LINK
Manual Included:
Shop Manual:
436 pages
Specifications:
Brand:
Komatsu
Model:
W120-3
Type:
Loader
Serial Number:
50001 and up
Manuals:
Shop Manual
Publication Number:
SEBM0383C01
Language:
English
Format:
PDF
Description
Table of Contents
General
Power Train
Steering System
Air System
Hydraulic System
Work Equipment
Others
Manual Extract INSPECTION OF STEERING LINKAGE:
• Check the tire inflation pressure of all four wheels, which must be the same ( Refer to "operation and maintenance manual" for specified pressure.) and place the machine on paved level ground and carry out following inspection.
1. Start engine and straighten both of front and rear frames by turning steering wheel. Apply safety bar on frame and stop the engine. Parking brake must be applied.
2. Check bolts and nuts of linkage for looseness and drug link ball joint for deflection. * A t this time, confirm that pitman arm is in right angle against the ground.
3. Start engine, and remove safety bar. Turn steering wheel until pitman arm contacts to the stopper (5).
Then, measure clearance between front and rear frame stoppers. The clearance should be 12.7 ± 6 mm.
