Komatsu W120-2 Wheel Loader Service Manual Workshop Guide
Komatsu W120-2 Wheel Loader Service Manual Workshop Guide
Regular price
$57.00 USD
Regular price
Sale price
$57.00 USD
Taxes included.
Shipping calculated at checkout.
Quantity
.
In Stock
Couldn't load pickup availability
Format : PDF
SUPPLIED AS DOWNLOADABLE LINK
Manual Included:
Shop Manual:
433 pages
Specifications:
Brand:
Komatsu
Model:
W120-2
Type:
Loader
Serial Number:
11001 and up
Manuals:
Shop Manual
Publication Number:
SEBM0383B01
Language:
English
Format:
PDF
Description
Table of Contents
General
Power Train
Steering System
Air System
Hydraulic System
Work Equipment
Others
Manual Extract:
The axle assemblies have three main functions; to transmit the out-going twisting force (torque) at 90° to the left and right of its input direction; increase the input torque through reduction gearing and provide a means of securing the wheels and at the same time, supporting the tractor. To each of these main functions several secondary requirements are added suggesting a complex piece of machinery. In reality, each axle uses a minimum of parts to accomplish its many functions. Simplicity of design increases reliability and provides easy servicing.
Both axles are full floating, double reduction type. The axles are rigidly attached to their supporting members; the front main frame in the case of the front axle and an oscillating cradle for the rear. The cradle in turn, is pinned to the rear main frame. The first gear reduction takes place in the differential; the second in the planetaries.
Each wheel revolves on two tapered roller bearings mounted on the axle spindle. The axles are full floating in that none of the weight is supported by, or transmitted to, the axle shafts. All weight on the axle is supported by the wheels, bearing and axle housing.
