Komatsu D155AX-8 Dozer Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
Shop Manual:
3121 pages
Operation and Maintenance Manual:
477 pages
Field Assembly Manual:
93 pages
Specifications:
Brand:
Komatsu
Model:
D155AX-8
Type:
Dozer
Serial Number:
100001 and up
Manuals:
Shop Manual, Operation and Maintenance Manual and Field Assembly Manual
Publication Numbers:
SEN06497-06, TEN00661-02 and GEN00128-02
Language:
English
Format:
PDF

Description
Table of Contents
Index and Foreword
Specification
Structure and Functions
Standard Value Table
Testing and Adjusting
Troubleshooting
Disassembly and Assembly
Appendix
Circuit Diagrams
Index
1. Bleeding air and flushing of cylinder with piston valve (blade lift cylinder)
i) While running the engine at low idle, extend and retract the cylinder for 5 minutes.
However, do not move the cylinder to the stroke end.
a Operate the piston rod to approx. 100 mm from the end of the stroke; do not relieve the circuit under any circumstances.
ii) Keeping the engine at low idle, retract the cylinder to a point approx. 100 mm before the end of the stroke, then use fine control (at least 10 seconds) to retract the cylinder to the end of its stroke. While operating the lever, hold the cylinder in this position for 3 minutes.
2. Bleeding air and flushing of cylinder without piston valve (Blade tilt cylinder, ripper lift cylinder, ripper tilt cylinder)
i) Check the oil level in the hydraulic tank.
(Check that the oil level is between "L" and "H" of the sight gauge. If it is not between "L" and "H", add oil.) a When checking the hydraulic oil level, see assembly procedure "A-10-4. Oil level check position".
ii) While running the engine at low idle, extend and retract the cylinder for 5 minutes.
However, do not move the cylinder to the stroke end.
a Operate the piston rod to approx. 100 mm from the end of the stroke; do not relieve the circuit under any circumstances.
