Kobelco 235SRLC-2 Hydraulic Excavator Repair Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
Shop Manual:
1121 Pages
Specifications:
Brand:
Kobelco
Model:
235SRLC-2
Serial Number:
YU05-02001-
Type:
Hydraulic Excavator
Manuals:
Shop Manual
Publication Numbers:
S5YF0006E01 NA (Jul 2007)
Language:
English
Format:
PDF

Description
TABLE OF CONTENT : Service manual
OUTLINE
SPECIFICATIONS
ATTACHMENT DIMENSIONS
TOOLS
STANDARD MAINTENANCE TIME SCHEDULE
MAINTENANCE STANDARD AND TEST PROCEDURE
MECHATRO CONTROL SYSTEM
HYDRAULIC SYSTEM
ELECTRICAL SYSTEM
AIR-CONDITIONER SYSTEM
DISASSEMBLING & ASSEMBLING
ATTACHMENT
UPPER STRUCTURE
TRAVEL SYSTEM
BY ERROR CODES
BY TROUBLE
TROUBLE DIAGNOSIS MODE
ENGINE
Preface Instructions
Read and understand all Warning plates and decal on the machine before Operating, Maintaining or Repairing this machine. The manual has been written for the repair specialist. The serviceman or mechanic may be unfamiliar with many of the systems on this machine. This makes it important to use this manual and be caution when performing service work.
Please go carefully through the manual of the excavator before starting any repair work. Use proper lifting procedures when removing any components. Be careful when removing filler caps, breathers and plugs on the machine. Hold a rag over the cap or plug to prevent being sprayed or splashed by liquids under pressure. The danger is even greater if the machine has just been stopped because fluids can be hot.
Use the Shop/Service Manual of the 235SRLC-2 as a reference book and source of information even if you are familiar with Excavator technology. Using the Repair Manual, the experience construction machine mechanic can carry out any necessary repairs expertly.
Sections of the Manual
This Manual is prepared as a technical material in which the information necessary for the maintenance and repairing services of our hydraulic excavators are collected, and is categorized into 7 Chapters, Specification, Maintenance, System, Disassembly, Troubleshooting, Engine, and Installation Procedures for Optional Attachment.
• The Chapter "Specification" describes the specifications for entire machine and material, which are instructive for replacement and repairing of attachments.
• The Chapter "Maintenance" describes the material, which is helpful for maintenance service and adjustments for entire machine.
• The Chapter "System" describes the operating system like hydraulic system, electric system, components, and so on.
• The Chapter "Disassembly" describes the removal and installing of assembly mounted on the upper structure and undercarriage, and the assembling and disassembling of the associated with the manual.
• The Chapter "Troubleshooting" describes how to find the fault equipment.
• The Chapter "Engine" describes the engines making use of the "Maintenance Manual" provided by the suppliers.
• The Chapter "Installation Procedures for Optional Attachment" describes the supplements added on request as required.
The number is assigned to every part handled in this Manual on account of the description, but the parts, which cannot be supplied as service parts are contained.
