John Deere TeamMate IV 1400 Series Inboard Planetary Axles Component Technical Manual Workshop Guide
John Deere TeamMate IV 1400 Series Inboard Planetary Axles Component Technical Manual Workshop Guide
Regular price
$66.00 USD
Regular price
Sale price
$66.00 USD
Taxes included.
Shipping calculated at checkout.
Quantity
.
In Stock
Couldn't load pickup availability
Format : PDF
SUPPLIED AS DOWNLOADABLE LINK
Manual Included:
Component Technical Manual:
276 Pages
Specifications:
Brand:
John Deere
Model:
TeamMate IV 1400 Series
Type:
Inboard Planetary Axles
Manuals:
Component Technical Manual
Publication Numbers:
CTM140219
Language:
English
Format:
PDF
Description
Table of Content
Section 01—General Information
Group 000—Safety
Group 005—General
Section 02—Repair and Adjustments
Group 010—Axle Oscillation Support
Group 020—Axle Repair Stand
Group 030—Input Housing
Group 030A—Input Housing with Internal Park Brake
Group 040—Final Drive Assembly
Group 050—Planetary Carrier Assembly
Group 060—Single Disk Service Brake
Group 060A—Dual Disk Service Brake
Group 070—Differential Case Assembly
Section 03—Theory of Operation
Group 100—Axle Operation
Section 04—Diagnostics
Group 200—Brake Inspection, Adjustments, Tests, and
Bleeding
Group 210—Operational Checks
Group 220—Differential and Axle Assembly Tests
Group 230—Troubleshooting
Section 05—Tools and Other Materials
Group 300—Special Tools
Group 310—Other Materials
Section 06—Specifications
Group 400—Bolts and Cap Screws Specifications
Group 410—Sealants and Adhesives Cross-Reference
Information is organized in groups for the various components requiring service instruction. At the-beginning of each group are summary listings of all applicable essential tools, service equipment and-tools, other materials needed to do the job, service parts kits, specifications, wear tolerances, and-torque values.
This component technical manual covers the recommended repair procedure for the TeamMate™ IV 1400 Series Inboard Planetary Axles.
Some components from these axles, such as axle housings, brakes, and input quills, may be serviced-without removing the complete axle assembly from the machine. You may have to determine this
procedure yourself for a safe removal of such components. See information to remove and install the-complete axle assembly, found in your vehicle technical manual.
