John Deere Front Wheel Drive Axles APL, 045 and AS Series Repair Manual (CTM4509) Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
Component Technical Manual:
250 Pages
Specifications:
Brand:
John Deere
Model:
Front Wheel Drive Axles APL, 045 and AS Series
Type:
Component Technical Manual
Publication Numbers:
CTM4509
Language:
English
Format:
PDF

Description
Table of contents
This manual is written for an experienced technician. Essential tools required in performing certain service work are identified in this manual and are recommended for use.
The FWD axle type plate on APL and AS model is located on the right-hand side of the axle housing, whereas on APL-2060 and As-2060 it is located on the left-hand side of the axle housing. The FWD axle type plate on APL-2045 with TLS is located on the right-hand side of the centre axle housing. Refer to the axle type shown on the plate to identify repair information in the Component Technical Manual
