John Deere 100K Synchronous Thinner Service Repair Manual (TM1074 & TM1023) Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
Technical Manual:
94 pages (TM1074) & 30 Pages (TM1023)
Specifications:
Brand:
John Deere
Model:
100K Synchronous Thinner
Type:
Attachment
Manuals:
Technical Manual
Publication Numbers:
TM1074 & TM1023
Language:
English
Format:
PDF

Description
Table of Content (Technical Manual – TM1074)
GENERAL
– Description
– Specifications
– Lubrication
– Diagnosing Malfunctions
ACTUATOR AND SOLENOID VALVE
– Actuator
– Solenoid Valve
– Specifications, Torque Value, and Special Tools
HYDRAULIC SYSTEM
General Information, Diagnosis, and Tests
– Hydraulic Motor
– Accumulators
– Hydraulic Hoses, Connections, and Valves
– Specifications and Special Tools
ELECTRICAL SYSTEM
– General Information, Diagnosis, and Tests
– Alternator
– Amplifier and Probe Wires
– Switch Box
– Specifications and Special Tools
GAUGING SYSTEM
– General Information and Diagnosing Malfunctions
– Rig Hanger, Cone Guide-Wheel, Rolling Coulter, Gauge Wheel, and Adjustments
Table of Content (Technical Manual – TM1023)
SECTION 10 – GENERAL
– Specifications
– Lubrication
SECTION 20 – ELECTRICAL SYSTEM
– Diagnosing System Malfunctions
– Wiring Diagrams
– Alternator
– Amplifier and Probe
– Solenoid
SECTION 30 – HYDRAULIC SYSTEM
– General Information and Testing
– Hydraulic Motor
– Actuator
– Valve, Accumulators and Manifolds
