JCB AA-6HK1T BB-6HK1T Engine Workshop Manual 9806-2200

JCB AA-6HK1T BB-6HK1T Engine Workshop Manual 9806-2200
======================================================

TECHNICAL SPECIFICATIONS:
----------------------------------------
Size: 14.63 MB
Pages: 241
Format: PDF
Language: English
Brand: JCB

CONTENTS (Table of Contents):
----------------------------------------
00 General Information
6A Engine Mechanical
6B Engine Cooling6C Engine Fuel
6D Starting and Charging
6E —
6F —
6G Engine Lubrication
6J Engine Induction
GENERAL INFORMATION 0A–1
GENERAL INFORMATION
General Repair Instruction. . . . . . . . . . . . . . . . . . . . 0A-1
General Repair Instruction
1. Before performing service operations, disconnect the
2. Use a cover on body, seats and floor to protect them
against damage and contamination.
3. Brake fluid and anti-freeze solution must be handled
with care because they can cause paint damage.
4. The use of proper tools and special tools, where
specified, is important for efficient and reliableperformance of service repairs.
5. Use genuine Isuzu parts.6. Used cotter pins, plastic clips, gaskets, O-rings oil
7.To facilitate proper and smooth reassembly
8. Clean the parts before inspection or reassembly. Also
clean oil ports, etc. using compressed air, and makecertain they are free from restrictions.
9. Lubricate rotating and sliding faces of the parts with
oil or grease before installation.
10.When necessary, use a sealer on gaskets to prevent
leakage.
11.Carefully observe all specifications for nut and bolt
torques.12.When a service operation is completed, make a final
check to be sure the service has been done properlyand the problem has been corrected.
13.Allow the engine to cool before beginning any service
procedure.
This will eliminate the danger of fire and possible
injury.
14.Hot steam under pressure may escape from the
15.Hot engine oil can cause severe skin burns. Allow the
engine to cool before draining the engine oil.
16.While working around a running engine, avoid contact
with moving parts and hot surfaces to prevent injury.
17.Wear safety glasses when using compressed air.
Flying particles may cause eye injury.
18.Always wear safety goggles when working with fuel to
protect the eyes from fuel splash.
19.Test fluid from the injection nozzle tester will spray out
of the injection nozzle under great pressure.
It can easily puncture a person’s skin.Keep your hands away from the injection nozzle at all
times.
20.Do not use your fingers to feel for fuel leaks at fittings.
Fuel pressure is high enough to penetrate the skin.
21.Be careful when changing fuel system components:

PLEASE NOTE:
----------------------------------------
This is a digital manual - no physical copy will be shipped.
The manual is available for immediate download after purchase.
