JCB 540-170 535-95 531-70 541-70 535-160 535-125 535-140 533-105 532-120 541-70 536-70 538-60 528-70 Loadall Factory Workshop Service Manual 9803/3665-3

JCB 540-170 535-95 531-70 541-70 535-160 535-125 535-140 533-105 532-120 541-70 536-70 538-60 528-70 Loadall Factory Workshop Service Manual 9803/3665-3
========================================================================================================================================================

TECHNICAL SPECIFICATIONS:
----------------------------------------
Size: 30.56 MB
Pages: 350
Format: PDF
Language: English
Brand: JCB

CONTENTS (Table of Contents):
----------------------------------------
About the Load Control Systems ...................................................................2
LCS (Six Valve Manifold)
LC1 and LC4 (540-170 Only)
LC2 and LC3
Circuit Description - 535-95, 531-70, 5 36-70 and 541-70 ...........................75
Circuit Description - 533-105 and 540-140 ..................................................86
Circuit Description - 535-125 HiViz and 535-140 HiViz ...............................99
Logic Sequence (All LC2/LC3 Systems) ...................................................131
MC05
MC06
Circuit Descriptions - Parallel Machin es ....................................................
ii iiCircuit Description - LSP + Gearpump Machines ......................................235
Circuit Description - LSP + Variflow Ma chines ..........................................250
Fault Finding
Testing and Adjustment
