JCB 2CX 2CXU 210S 210SU Backhoe Loader Factory Workshop Service Manual 9803/7130-08

JCB 2CX 2CXU 210S 210SU Backhoe Loader Factory Workshop Service Manual 9803/7130-08
===================================================================================

TECHNICAL SPECIFICATIONS:
----------------------------------------
Size: 76.02 MB
Pages: 965
Format: PDF
Language: English
Brand: JCB

CONTENTS (Table of Contents):
----------------------------------------
Using the Service Manual .....................................................................1-1
Machine Nomenclature .. .......................................................................1-2
Machine Identification
Typical Vehicle Identification Number (VIN) ..........................................1-3
Typical Product Identification Number (PIN) .........................................1-4
Component Identification Plates ................................................................
Typical Engine Identificati on Number ....................................................1-5
Transmission Identification Numbers ....................................................1-6
Torque Settings
Zinc Plated Fasteners and Dacromet Fasteners .......................................
'O' Ring Face Seal System ..................................................................
'Torque Stop' Hose System .................................................................1-14
Service Tools
Service Aids
Sealing and Retaining Compounds .........................................................
Terms and Definitions
Hydraulic Schematic Colour Codes .....................................................1-23
1-ii 1-ii
Using the Service Manual
T11-004
Distributor Service Engineers who are receiving, or have
received, training by JCB Technical Training Department.
These personnel should have a sound knowledge of
hydraulic earthmoving equipment.
Where the machines differ, the text and/or the illustration
will specify.
Renewal of oil seals, gaskets, etc., and any component
showing obvious signs of wear or damage is expected as
a matter of course. It is ex pected that components will be
cleaned and lubricated where ap propriate, and that any
opened hose or pipe connections will be blanked to
prevent excessive loss of hydraulic fluid and ingress of dirt.
Where a torque setting is given as a single figure it may be
varied by plus or minus 3%. Torque figures indicated are
for dry threads, hence for lubricated threads may be reduced by one third.
The manufacturer's policy is one of continuous
improvement. The right to change the specification of the
machine without notice is reserved. No responsibility will
Finally, please remember above all else safety must come
first!
T11-005
with Dismantling, Overhaul etc. of specific components, for
example:
Left Side, Right Side
In this manual, ‘left’ A and ‘right’ B mean your left and right
C003690
Fig 1. 1 General Information - includes torque settings and
service tools.
2 Care and Safety - includes warnings and cautions
pertinent to aspects of workshop procedures etc.
3 Maintenance - includes service schedules and
recommended lubricants for all the machine.
A Attachments
B Body and Framework, etc.

PLEASE NOTE:
----------------------------------------
This is a digital manual - no physical copy will be shipped.
The manual is available for immediate download after purchase.
