JCB TLT 30D, TLT 35D 4×4, TLT 30D High Lift Teletruck Service Manual Workshop Guide
JCB TLT 30D, TLT 35D 4×4, TLT 30D High Lift Teletruck Service Manual Workshop Guide
Regular price
$63.00 USD
Regular price
Sale price
$63.00 USD
Taxes included.
Shipping calculated at checkout.
Quantity
.
In Stock
Couldn't load pickup availability
Format : PDF
SUPPLIED AS DOWNLOADABLE LINK
Model:
Teletruk
TLT 30D, TLT 35D 4×4, TLT 30D
Language: English
Format PDF
Type: Service Manual
Publication No: 9813/2500 & 9822/0435
Machine Model and Serial Number
JCB TLT 30D, TLT 35D 4×4, TLT 30D High Lift Teletruck Service Manual 1100 Pages
See description below for applicable serial numbers
Description
JCB TLT 30D, TLT 35D 4×4, TLT 30D High Lift Teletruck Service Manual
Model:
Teletruk
TLT 30D, TLT 35D 4×4, TLT 30D
Language: English
Format PDF
Type: Service Manual
Publication No: 9813/2500 & 9822/0435
Machine Model and Serial Number
JCB TLT 30D, TLT 35D 4×4, TLT 30D High Lift Teletruck Service Manual 1100 Pages
Applicable serial number:
1540935-1541999,
2317866-2318866,
2498451-2499000,
2707511-2708710,
2252520-2252525
Section Numbering
The first three sections of this manual are numbered and contain the following information:
1 General Information includes torque settings and service tools.
2 Care and Safety includes warnings and cautions pertinent to aspects of workshop procedures etc.
3 Maintenance includes service schedules and recommended lubricants for all the machine.
The remaining sections are alphabetically coded and deal with Dismantling, Overhaul etc. of specific components, for example:
A Attachments
B Body and Framework, etc.
Section contents, technical data, circuit descriptions, operation descriptions etc. are present at the beginning of each alphabetically coded section.
JCB TLT 30D, TLT 30D 4×4, TLT 30D High Lift Teletruck Service Manual Content:
01 – Machine
03 – Attachments and Options
06 – Body and Framework
09 – Operator Station
12 – Heating, Ventilating and Air-
Conditioning (HVAC)
15 – Engine
18 – Fuel and Exhaust System
21 – Cooling System
24 – Brakes
25 – Steering System
27 – Driveline
30 – Hydraulic System
33 – Electrical System
72 – Fasteners and Fixings
75 – Consumable Products
78 – After Sales
Where a torque setting is specify as a single figure it may vary by plus or minus 3%. Torque figures indicated are for dry threads, hence for lubrication threads may be reduce by one third.
