JCB 2DXL Loader Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

JCB 2XL Backhoe Loader Service Manual – 724 Pages
Publication No: EN – 9813/5500 – ISSUE 1 – 01/2016
Language: English
Format PDF
Type:
Backhoe Loader

Description
JCB 2DXL Loader Service Manual
Machine Model and Serial Number
This manual provides information for the following model(s) in the JCB machine range:
JCB 2XL Backhoe Loader Service Manual – 724 Pages
Publication No: EN – 9813/5500 – ISSUE 1 – 01/2016
Language: English
Format PDF
Type:
Backhoe Loader
JCB 2XL Loader Service Manual Service Manual Section Numbering
The first three sections of this manual are numbered and contain the following information:
1 General Information – includes torque settings and service tools.
2 Care and Safety – includes warnings and cautions pertinent to aspects of workshop procedures etc.
3 Maintenance – includes service schedules and recommended lubricants for all the machine.
The remaining sections are alphabetically coded and deal with Dismantling, Overhaul etc. of specific components, for example:
A Attachments
B Body and Framework, etc.
Section contents, technical data, circuit descriptions, operation descriptions etc. are inserted at the beginning of each alphabetically coded section.
JCB 2DXL Loader Service Manual Content:
01 – Machine
03 – Attachments
06 – Body and Framework
09 – Operator Station
15 – Engine
18 – Fuel and Exhaust System
21 – Cooling System
24 – Brakes
25 – Steering System
27 – Driveline
30 – Hydraulic System
33 – Electrical System
72 – Fasteners and Fixings
75 – Consumable Products
78 – After Sales
