Fendt 3X, 4X, 5X Front Loader Service Manual Workshop Guide
Fendt 3X, 4X, 5X Front Loader Service Manual Workshop Guide
Regular price
$51.00 USD
Regular price
Sale price
$51.00 USD
Taxes included.
Shipping calculated at checkout.
Quantity
.
In Stock
Couldn't load pickup availability
Format : PDF
SUPPLIED AS DOWNLOADABLE LINK
Fendt CARGO 3X front loader (Standard),
Fendt CARGO 4X/5X front loader (Standard and Profi),
Fendt CARGO R rear loader
Service Manual of 492 Pages
Description
Fendt 3X, 4X, 5X Front Loader Service Manual
Manual for:
AGCO Fendt
Format: PDF
Book Number: X990.005.461.013
English
Issued July 2013
Fendt CARGO 3X front loader (Standard),
Fendt CARGO 4X/5X front loader (Standard and Profi),
Fendt CARGO R rear loader
Service Manual of 492 Pages
Service Manual TABLE OF CONTENTS
General
Faults
Documents and Diagrams
Component Location
Testing
Setting and Calibration
Repair
Service info
Preliminary work:
– Apply the hand brake.
Raise and fold up the lower links of the front hydraulic power lift (FENDT 400/700/800 Vario) Check front air pressure and track adjustment.
Drive the tractor slowly into the front-loader console.
Clean the mating faces of the multi-coupler.
Insert the multi-coupler with integrated electric lines.
Swivel the bracket downwards until catch (A) snaps into place.
NOTE: Do not load the foldaway supports by using the DA function to lift the front loader out of the mounting console. Doing this may damage the foldaway supports.
