CASE International 523 624 724 Diesel Tractor Transmission Factory Workshop Service Manual 3000730R2

CASE International 523 624 724 Diesel Tractor Transmission Factory Workshop Service Manual 3000730R2
====================================================================================================

TECHNICAL SPECIFICATIONS:
----------------------------------------
Size: 40.48 MB
Pages: 126
Format: PDF
Language: English
Brand: CASE

CONTENTS (Table of Contents):
----------------------------------------
- Index

- Transmission General

- Speed Charts

- Powershift Transmission

- Powershift System - 523/624/724
- Powershift System - 3654

- Lever Positions in Road Range (Two Spool Control Valve 523/624/724)
- Lever Positions in Field Range (One-Spool Control Valve 523/624/724)

- Lever Positions in Reverse Range (One-Spool Control Valve)

- Separating The Engine From The Transmission

- Control Valve Lever 523/624/724

- Powershift Hydraulic Pump 523/624/724
- Powershift Hydraulic Pump, Relief Valves and Oil Cooler - 3654 Loader

- One-Spool Control Valve For Powershift Transmission 3654

- Hydraulic Lines

- Shifter Rods and Linkage

- Main Drive Shaft and Synchronizer Units 523/624/724

- Front Countershaft With Clutch Packs

- Spline Shaft and Range Transmission

- Differential

- Differential Lock

- Rear Countershaft and Reverse Idler Gear

- Power Take-off

- Ground Speed PTO 523/624/724

- Independent PTO - and Four Wheel Drive 523/624/724

- Mechanical (Non-Powershift) Transmission

- Special Tools

- Trouble Shooting

PLEASE NOTE:
----------------------------------------
This is a digital manual - no physical copy will be shipped.
The manual is available for immediate download after purchase.
