Case WX218 Wheeled Excavator Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
•
Service Manual:
1229 pages
Specifications:
•
Brand:
New Holland
•
Model:
WX218
•
Type:
Excavator
•
Manuals:
Service Manual
•
Publication Numbers:
48005326 (April 2016)
•
Language:
English
•
Format:
PDF

Description
Table of Contents
Contents
Introduction
Engine
Transmission
Four Wheel Drive
Front Axle
Rear Axle
Brakes and controls
Hydraulic systems
Frames and ballasting
Steering
Wheels
Cab climate control
Electrical systems
Booms, dippers and buckets
Dozer blade and arm
Platform, cab, bodywork and decals
Special Tool index
Manual Extract: Axle suspension cylinder – Remove
1. Park the machine on a level and firm surface.
2. Rest the working attachment on the ground.
3. Lock the upper structure.
4. Engage the parking brake.
5. Stop the engine.
6. Move both hydraulic control levers in all directions, to release possible residual pressure inside the hydraulic system.
7. Disconnect the pilot control.
8. Set the starter switch key to position "0" and pull it out.
9. Place some wedges under the wheels so as to prevent the machine from moving.
10. Disconnect the hydraulic hoses (4) from the axle floating locking cylinders (1).
11. Close all openings on hoses and cylinders with plugs in order to prevent dirt from entering.
12. Measure the distance between the end of the cylinder and the supporting base of the axle.
13. Correctly sling the cylinder (1).
14. Unscrew and remove the screws (3) and bushings (2).
15. Now the axle floating blocking cylinder (1) can be removed.
