Case STX280, STX330, STX380, STX430, STX480, STX530 Steiger Tractor Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
•
Service Manual:
3348 pages
Specifications:
•
Brand:
Case
•
Model:
STX280, STX330, STX380, STX430, STX480, STX530 MX Magnum
•
Type:
Tractor
•
Manuals:
Service Manual
•
Publication Number:
84257307 – 1
•
Language:
English
•
Format:
PDF

Description
Table of Contents
General
Engine
Electrical
Steering
Power Train
Brakes
Hydraulics
Chassis
Controllers
Electrical Schematic
Hydraulic Schematic
Manual Extract: TRANSMISSION TROUBLESHOOTING
The transmission system is controlled and monitored by the transmission controller. The controller is located below the right hand console in the electrical compartment.
Before starting any troubleshooting procedures check the wiring harness and components for damaged or loose connections. Replace or repair any damaged parts as necessary.
Be sure to check the transmission oil level. Check for excessive leakage at hoses and hydraulic components and valves.
The transmission oil must be warmed to more than 60 degrees C (140 degrees F).
Transmission troubleshooting begins by checking for transmission fault codes. If fault codes exist, record the fault codes, clear all the fault codes, operate the machine and see if the fault codes are repeated.
Fault Code Retrieval
Controllers can be checked for fault codes at any time. Up to 10 fault codes can be stored in each controller.
