Case SR270, SV300, SV340, TR340, TV380 SkidSteer Service Manual (Tier 4B) Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Details:
•
Service Manual:
2330 Pages (Publication 48060319),
2492 Pages (Publication 47916277 ),
2844 Pages (Publication 47685161)
Specifications:
•
Brand:
Case
•
Model:
PIN NFM481941 and above (Applicable for SR270 & SV300)
PIN NGM418237 and above (Applicable for SR270, SV340, TR340, TV340)
PIN NHM435463 and above (Applicable for SR270, SV340, TR340, TV340)
•
Type:
SkidSteer
•
Manuals:
Service Manual
•
Publication Numbers:
48060319 (Nov 2017), 47916277 (Oct 2016) and 47685161 (June 2015)
•
Language:
English
•
Format:
PDF

Description
Table of Contents
Contents
Introduction
Engine
Power Coupling
Front Axle System
Rear Axle System
Hydrostatic Drive
Brakes and Controls
Hydraulic Systems
Frames and Ballasting
Wheels
Track and track suspension
Cab Climate Control
Electrical System
Front Loader and Bucket
Platform, Cab, Bodywork and Decals
Specials Tool Index
Electronic Schematics
Hydraulic Schematics
Manual Extract: Loader bucket control cylinder – Disassemble
1. Clean the outside of the cylinder. If the hoses were removed from the cylinder, remove the hoses.
2. Fasten the tube (1) in a vise, or other holding equipment can be used. Be careful not to damage the tube.
3. Loosen the gland (5) in the tube with a gland wrench.
4. To prevent damage to the tube, pull the piston rod (3) straight out of the tube.
5. Fasten the piston rod end in a vise. To prevent damage to the piston rod, place a padded support below the piston rod near the piston.
6. Loosen and remove the bolt (14) and the washer (16) that connects the piston on the piston rod.
7. Remove the piston (6) from the piston rod.
8. Remove and discard the seal (11), wear ring (13) and backup ring (12) from the piston.
9. Remove and discard the O-ring (9), backup ring (10), seals (8), and wiper (7) from the gland (5).
