Case Puma 150, 165 CVT Tractor Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
•
Service Manual:
5365 pages
Specifications:
•
Brand:
Case
•
Model:
Puma 150, 165 CVT
•
Type:
Tractor
•
Manuals:
Service Manual
•
Publication Numbers:
47936459 (Jan 2016)
•
Language:
English
•
Format:
PDF

Description
Table of Contents
Introduction
Engine
Clutch
Transmission
Four Wheel Drive
Front Axle
Rear Axle
Power Take Off
Brake and Controls
Hydraulic Systems
Pneumatic System
Hitches, Drawbars and implement couplings
Frames and ballasting
Steering
Wheels
Cab climate control
Electrical System
Platform, cab, bodywork and decals
Special Tools
Manual Extract:
Transmission control valve – Assemble
Prior operation:
Disassemble the control valve, for further information refer to Transmission control valve – Disassemble (21.133).
1. Install four new O-ring seals.
For further information, refer to Semi-Powershift transmission – Sectional view (21.111).
NOTE: Wait 15 minutes before installing the piston into the bore.
2. Install the inner piston.
3. Install the inner retaining ring.
4. Install the piston and ring.
5. Install the circlip.
6. Install the retaining cap.
7. Install the circlip.
8. Repeat steps 1 to 7 to assemble the remaining piston (if disassembled).
