Case Puma 130, 145, 160 CVT Tractor Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
•
Service Manual:
2464 pages
Specifications:
•
Brand:
Case
•
Model:
Puma 130, 145, 160 CVT
•
Type:
Tractor
•
Manuals:
Service Manual
•
Publication Number:
84479138A (Sep 2011)
•
Language:
English
•
Format:
PDF

Description
Table of Contents
Introduction
Hydraulic
Pneumatic
Electrical
Electronic System
Engine
Power Take Off (PTO)
Axles
Brakes
Steering
Frames and Cab
Hitch and Working Tool
Special Tools
Manual Extract: Manual Clutch Adjustment
NOTE: This channel is used to manually adjust and test the calibration values for each clutch.
Select the clutch to be adjusted by depressing the clutch pedal and either shifting the shuttle lever into forward to select the A clutch or shifting the shuttle lever into reverse to select the B clutch.
The display will show the clutch letter for 1 second and then show the calibration value.
The calibration values can then be adjusted using the forward or reverse shuttle buttons on the hand controller.
To test the calibration fully release the clutch pedal, the selected clutch will be applied at the adjusted current.
