Case Puma 115, 125, 140, 155 Tractor Service Manual Workshop Guide
Case Puma 115, 125, 140, 155 Tractor Service Manual Workshop Guide
Regular price
$67.50 USD
Regular price
Sale price
$67.50 USD
Taxes included.
Shipping calculated at checkout.
Quantity
.
In Stock
Couldn't load pickup availability
Format : PDF
SUPPLIED AS DOWNLOADABLE LINK
Manual Included:
•
Service Manual:
3761 pages
Specifications:
•
Brand:
Case
•
Model:
Puma 115, 125, 140, 155
•
Type:
Tractor
•
Manuals:
Service Manual
•
Publication Number:
87727132BNA (April 2010)
•
Language:
English
•
Format:
PDF
Description
Table of Content (
Service Manual)
Introduction
Hydraulic
Pneumatic
Electrical
Electronic System
Engine
PTO
Transmission
Drive and PTO out
Axles
Brakes and Steering
Frame and Cab
Hitch and Working Tool
Manual Extract: PRIMARY HYDRAULIC POWER SYSTEM Electro-hydraulic remote valve
Static description Activity
Each remote valve has its own built in microprocessor which controls the oil flow through a solenoid activated valve, based on inputs received from the operator controlled switches.
Each remote valve is connected into the electrical CAN BUS system to the RK / RL control module, located behind the drivers seat. Each remote valve can also detect system faults and send a message to the RK / RL module which in turn sends a signal to allow a fault code to be displayed on the instrument cluster.
Refer to the fault code list for relevant information.
Control Levers
The electro-hydraulic remote valves are operated by control levers in the right-hand console. Each control lever is coloured to correspond to the color on the remote valve. A maximum of four electro-hydraulic remote valves may be fitted.
