Case Farmall 85A, 95A, 105A, 115A Tractor Service Repair Manual Workshop Guide
Case Farmall 85A, 95A, 105A, 115A Tractor Service Repair Manual Workshop Guide
Regular price
$76.50 USD
Regular price
Sale price
$76.50 USD
Taxes included.
Shipping calculated at checkout.
Quantity
.
In Stock
Couldn't load pickup availability
Format : PDF
SUPPLIED AS DOWNLOADABLE LINK
Manual Included:
Service Repair Manual:
1987 pages
Operators Manual:
368 pages
Specifications:
Brand:
Case
Model:
85A, 95A, 105A, 115A
Type:
Tractor
Manuals:
Service Repair Manual and Operators Manual
Publication Numbers:
51559261, 48013245 and 48194628
Language:
English
Format:
PDF
Description
Table of Contents
Introduction
Engine
Clutch
Transmission
Four Wheel Drive
Front Axle
Rear Axle
Power Take Off
Brake and Controls
Hydraulic Systems
Steering
Wheels
Cab Climate Control
Electrical System
Platform, cab, bodywork and decals
Special Tools
Important notice
All maintenance and repair operations described in this manual should be carried out exclusively by the CASE IH authorized workshops. All instructions detailed should be carefully observed and special equipment indicated should be used if necessary.
Everyone who carries out service operations described without carefully observing these prescriptions will be directly
responsible of deriving damages.
Shimming
At each adjustment, select adjusting shims, measure them individually using a micrometer and then sum up recorded
values. Do not rely on measuring the whole shimming set, which may be incorrect, or on rated value indicated for
each shim.
Rotating shaft seals
To correctly install rotating shaft seals, observe the following instructions:
• Let the seal soak into the same oil as it will seal for at least half an hour before mounting.
• Thoroughly clean the shaft and ensure that the shaft working surface is not damaged.
• Place the sealing lip towards the fluid. In case of a hydrodynamic lip, consider the shaft rotation direction and orient grooves in order that they deviate the fluid towards the inner side of the seal.
• Coat the sealing lip with a thin layer of lubricant (oil rather than grease) and fill with grease the gap between the sealing lip and the dust lip of double lip seals.
• Insert the seal into its seat and press it down using a flat punch. Do no tap the seal with a hammer or a drift.
• Take care to insert the seal perpendicularly to its seat while you are pressing it. Once the seal is settled, ensure that it contacts the thrust element if required.
• To prevent damaging the sealing lip against the shaft, place a suitable protection during installation. O-rings
Lubricate the O-rings before inserting them into their seats. This will prevent the O-rings from rolling over and twine during mounting which will jeopardies sealing.
