Case Farmall 75C Efficient Power Tractor Service Manual Workshop Guide
Case Farmall 75C Efficient Power Tractor Service Manual Workshop Guide
Regular price
$61.50 USD
Regular price
Sale price
$61.50 USD
Taxes included.
Shipping calculated at checkout.
Quantity
.
In Stock
Couldn't load pickup availability
Format : PDF
SUPPLIED AS DOWNLOADABLE LINK
Manual Included:
•
Service Manual:
1972 pages
Specifications:
•
Brand:
Case
•
Model:
Farmall 75C
•
Type:
Tractor
•
Manuals:
Service Manual
•
Publication Numbers:
47711472 (May 2014)
•
Language:
English
•
Format:
PDF
Description
Table of Contents
Content
Introduction
Engine
Clutch
Transmission
Four Wheel Drive
Front Axle
Rear Axle
Power Take Off
Brake and Controls
Hydraulic Systems
Hitches, Drawbars and implement couplings
Steering
Wheels
Cab climate control
Electrical System
Front Loader and Bucket
Platform, cab, bodywork and decals
Special Tools
Manual Extract:
Hydraulic systems – Dynamic description
The tractor is fitted with oil immersed brakes located in each rear axle trumpet housing.
The brakes are operated by two pedals which can be operated locked together or individually for field operation.
The pedals operate two master cylinders which supply oil through connecting pipe (2) to the two slave cylinders mounted on the axle housings. The slave cylinder actuator rod (3) is connected to expanding brake caliper (4).
The brake caliper (4) has internal tapered grooves with balls (5) between each half allowing the caliper to expand as the actuator rod is pulled. Brake discs (6) are mounted on the internal splines of the axle shaft (7).
When Brake pedals are pressed, pressurized oil is supplied to brake slave cylinder (1) through pipe (2).
The slave cylinder piston moves forward pulling the actuator rod which make the caliper (4) expand which presses the brake discs (6) against the transmission case and brake housing and so applying braking effect to the axle shaft (7).
