Case Farmall 50A, 60A, 70A Tractor Service Manual Workshop Guide
Case Farmall 50A, 60A, 70A Tractor Service Manual Workshop Guide
Regular price
$58.50 USD
Regular price
Sale price
$58.50 USD
Taxes included.
Shipping calculated at checkout.
Quantity
.
In Stock
Couldn't load pickup availability
Format : PDF
SUPPLIED AS DOWNLOADABLE LINK
Manual Included:
•
Service Manual:
1061 pages
Specifications:
•
Brand:
Case
•
Model:
Farmall 50A, 60A, 70A
•
Type:
Tractor
•
Manuals:
Service Manual
•
Publication Numbers:
47866582 (Dec 2015)
•
Language:
English
•
Format:
PDF
Description
Table of Contents
Introduction
Engine
Clutch
Transmission
Four Wheel Drive
Front Axle
Rear Axle
Power Take Off
Brake and Controls
Hydraulic Systems
Steering
Wheels
Electrical System
Platform, cab, bodywork and decals
Special Tools
Manual Extract:
Mechanical transmission external controls – Adjust
Shuttle interlock cable
1. Measure dimension (A) at cable end as shown in figure 1. (Top of nut to bottom of threads). The desired length of (A) is approximately 26.000 mm (1.024 in), adjust if required.
2. At the opposite cable end, count the number of visible threads (B), there should be 6 or 7. Thread length can be changed by adjusting the nuts on either side of cable mounting bracket (C).
3. Adjust the nuts so that the shuttle lever starts to move when clutch pedal is depressed beyond free play 50.00 – 55.00 mm (1.97 – 2.17 in) from rest) and then tighten.
