Case Farmall 45C, 55C Tractor Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
•
Service Manual:
2209 pages and 1841 pages
Specifications:
•
Brand:
Case
•
Model:
Farmall 45C, 55C, Farmall 45C CVT, 55C CVT
•
Type:
Tractor
•
Manuals:
Service Manual
•
Publication Numbers:
48144021 (June 2017) and 47851945 (Feb 2016)
•
Language:
English
•
Format:
PDF

Description
Table of Contents
Introduction
Engine
Clutch
Power Coupling
Transmission
Four Wheel Drive
Front Axle
Rear Axle
Hydrostatic Drive
Power Take Off
Brake and Controls
Hydraulic Systems
Hitches, Drawbars and implement couplings
Steering
Wheels
Cab climate control
Electrical System
Platform, cab, bodywork and decals
Special Tools
Electrical Schematics (ROPS & CABS)
Manual Extract:
Hydrostatic drive – Mechanical control
Adjustment
1. To achieve the correct HST pedal return spring setting do the following:
1. Hook the spring (1) to the neutral arm (2).
2. Hook the adjustable bolt (3) to the spring (1).
3. Install one Hex nut (4) to the adjustable bolt (3).
4. Put the adjustable bolt through the spring bracket (5).
5. Install the second hex nut (6) on the end of the adjustable bolt (3).
6. Draw tension on the spring (1) by rotating the second hex nut (6) in a clockwise direction.
7. When measurement (A) is 133 – 137 mm (5 – 5.4 in), secure in place with hex nut (4).
