Case Farmall 40C, 50C Tractor Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
•
Service Manual:
1817 pages
Specifications:
•
Brand:
Case
•
Model:
Farmall 40C, 50C
•
Type:
Tractor
•
Manuals:
Service Manual
•
Publication Numbers:
47941906 (Mar 2016)
•
Language:
English
•
Format:
PDF

Description
Table of Contents
Introduction
Engine
Clutch
Transmission
Front Axle
Rear Axle
Hydrostatic Drive
Power Take Off
Brake and Controls
Hydraulic Systems
Hitches, Drawbars and implement couplings
Steering
Wheels
Cab climate control
Electrical System
Platform, cab, bodywork and decals
Special Tools
Electrical Schematics
Manual Extract:
Powered front axle – Overview Front-Wheel Drive(FWD) lever
The Front-Wheel Drive (FWD) is controlled by a lever.
The lever is located on the left-hand of the operators platform, next to the park brake.
NOTE: Use front-wheel drive when additional traction is required while operating on loose soil, in wet, slippery conditions, or on slopes. For normal operation on firm soil, level hard surfaces, or when operating the unit at high speeds, disengage the
front-wheel drive to maximize tire and driveline life and to economize on fuel.
Gear model
To engage the front-wheel drive on gear model tractors, stop the tractor completely, depress the clutch pedal and push the lever (1) down. To disengage the front-wheel drive, stop the tractor completely, depress the clutch pedal and pull the lever (1) completely up.
Hydrostatic Transmission (HST) model
To engage the front-wheel drive on Hydrostatic Transmission (HST) model tractors, stop the tractor completely and push the lever (1) down. To disengage the front-wheel drive, stop the tractor completely and pull the lever (1) completely up
