Case Farmall 30A, 35A, 40A Tractor Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
•
Service Manual:
1591 pages and 1253 pages
Specifications:
•
Brand:
Case
•
Model:
Farmall 35A, 40A and Farmall 30A, 35A
•
Type:
Tractor
•
Manuals:
Service Manual
•
Publication Numbers:
48144025 (Jun 2017) & 47881876 (Jan 2016)
•
Language:
English
•
Format:
PDF

Description
Table of Contents
Introduction
Engine
Clutch
Transmission
Four Wheel Drive (4WD)
Front Axle
Rear Axle
Hydrostatic Drive
Power Take Off
Brake and Controls
Hydraulic Systems
Hitches, Drawbars and implement couplings
Steering
Cab climate control
Electrical System
Platform, cab, bodywork and decals
Special Tools
Electrical Schematics
Manual Extract:
Steering cylinder – Install
Prior operation:
Steering cylinder – Overhaul – Assemble (41.216) 1. Place steering cylinder in place as shown (1).
2. Secure the cylinder end by placing the zerked pin (1) through the end, and secure with a snap ring (2).
3. Secure the cylinder by inserting pin (1) upward and secure the pin with a bolt (2).
