Case CX80C Midi Excavator Service Manual Workshop Guide
Case CX80C Midi Excavator Service Manual Workshop Guide
Regular price
$61.50 USD
Regular price
Sale price
$61.50 USD
Taxes included.
Shipping calculated at checkout.
Quantity
.
In Stock
Couldn't load pickup availability
Format : PDF
SUPPLIED AS DOWNLOADABLE LINK
Manual Included:
Service Manual:
2303 Pages & 1774 Pages
Specifications:
Brand:
New Holland
Model:
Case CX80C
Type:
Midi Excavator
Manuals:
Service Manual
Publication Numbers:
47575340A (July 2013) and 48098410 (May 2015)
Language:
English
Format:
PDF
Description
Table of Contents
Content
Introduction
Engine
Hydraulics System
Frames and Ballasting
Tracks and Track Suspension
Cab Climate Control
Electrical System
Booms, dippers and buckets
Dozer Blade and Arm
Platform, cab, bodywork and decals
Special Tools Index
Electrical Schematic
Hydraulic Schematic
Manual Extract: Boom lifting cylinder holding valve – Remove
1. Remove the boom cylinder. For details, see " Boom cylinder – Remove (35.736)".
2. Use a wrench [ 17 mm] to remove the bolt (1), and use a wrench [ 36 mm] to remove the line (2).
• Use caps or plugs to cover the HBCV and lines to prevent any entry of water, dust or dirt.
• Clean the HBCV and lines by spraying them with a parts cleaner to prevent scratches and prevent dirt from accumulating on the connectors.
3. Use wrenches [ 27 mm, 36 mm] to remove the line (1).
• Use caps or plugs to cover the HBCV and lines to prevent any entry of water, dust or dirt.
• Clean the HBCV and lines by spraying them with a parts cleaner to prevent scratches and prevent dirt from accumulating on the connectors.
4. Use a wrench [ 17 mm] to remove the 2 bolts (1), and then remove the boom HBCV (2).
• Tightening torque for bolt installation: unknown
