Case CX800B Crawler Excavator Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
•
Service Manual:
2710 pages
Specifications:
•
Brand:
New Holland
•
Model:
CX800B
•
Type:
Excavator
•
Manuals:
Service Manual
•
Publication Numbers:
48020292 (June 2016)
•
Language:
English
•
Format:
PDF

Description
Table of Contents
Contents
Introduction
Engine
Hydraulic systems
Frames and ballasting
Tracks and track suspension
Cab climate control
Electrical systems
Booms, dippers and buckets
Platform, cab, bodywork and decals
Special Tool index
Hydraulic Schematics
Electrical Schematics
Manual Extract:  Turbocharger exhaust pipe installation
1. Install the gasket to the turbocharger exhaust pipe (1).
NOTICE: Make sure to install the gasket with its yellow marking surface installed to the turbocharger exhaust pipe (1) so that it can be seen.
Do not deform the gasket when installing. Install a new gasket.
Do not reuse the gasket.
2. Install the turbocharger exhaust pipe (1) to the turbocharger assembly (2).
NOTE: Install the V-band (3) to the turbocharger exhaust pipe (1).
NOTICE: Make sure there are no gasket fragments in the turbocharger exhaust pipe (1).
Insert the turbocharger exhaust pipe (1) until it makes full contact.
Tightening torque: 16 N·m (11.80 lb ft) PAWE1BSH005601 72
3. Install the turbocharger exhaust pipe (3) to the bracket.
Tightening torque: 50 N·m (36.88 lb ft) 1. Exhaust pipe bracket
2. V-band
