Case CX350D, CX370D Excavator Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
•
Service Manual:
3933 pages and 3312 Pages
Specifications:
•
Brand:
New Holland
•
Model:
CX350D and CX370D
•
Type:
Excavator LC and NLC Version
•
Manuals:
Service Manual
•
Publication Numbers:
47843026 (Mar 2015) & 51481238 (May 2018)
•
Language:
English
•
Format:
PDF

Description
Table of Content (
Service Manual)
Content
Introduction
Engine
Hydraulics System
Frames and Ballasting
Tracks and Track Suspension
Cab Climate Control
Electrical System
Booms, dippers and buckets
Dozer Blade and Arm
Platform, cab, bodywork and decals
Special Tools Index
Hydraulic Schematics
Electrical Schematics
Manual Extract: Arm cylinder holding valve – Remove
1. Use a wrench [ 22 mm] to remove the lines (1) (2).
• Mark the HBCV and line locations so that the connectors match at the time of installation.
• Use caps or plugs to cover the lines and HBCV to prevent any entry of water, dust or dirt.
• Clean the lines and HBCV by spraying them with a parts cleaner to prevent scratches and prevent dirt from accumulating on the connectors.
2. Use a hexagon wrench [ 10 mm] to remove the 4 hexagon socket head bolts (1), and then remove the line (2) and O-ring (3).
• Use caps or plugs to cover the HBCV and line to prevent any entry of water, dust or dirt.
• Clean the HBCV and line by spraying them with a parts cleaner to prevent scratches and prevent dirt from accumulating on the connectors.
3. Use a hexagon wrench [ 10 mm] to remove the 4 hexagon socket head bolts (1), and then remove the arm HBCV (2) and O-ring (3).
