Case CX290D Crawler Excavator Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
•
Service Manual:
3950 pages
Specifications:
•
Brand:
New Holland
•
Model:
CX290D
•
Type:
Excavator
•
Manuals:
Service Manual
•
Publication Numbers:
48155069 (Feb 2018)
•
Language:
English
•
Format:
PDF

Description
Table of Contents
Content
Introduction
Engine
Hydraulics System
Frames and Ballasting
Tracks and Track Suspension
Cab Climate Control
Electrical System
Booms, dippers and buckets
Platform, cab, bodywork and decals
Special Tools Index
Hydraulic Schematics
Electrical Schematics
Manual Extract: Bucket Removal
1. Set the maximum operating radius posture and place the club bucket nail in an opened state on the ground.
i Club bucket side pin
ii. Arm side pin
2. Remove the pin (2) ring (1) by using a driver.
Pull out the pins at the bucket side and the arm side.
3. Push out the pin (3) of club bucket side and pin (2) of arm side with a hammer (4) and striking rod (5) to remove the club bucket (1).
• When pulling out the pin, be careful not to damage the attached O-ring and dust seal.
