Case CX260C Excavator Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
•
Service Manual:
2607 pages
Specifications:
•
Brand:
New Holland
•
Model:
CX260C
•
Type:
Excavator
•
Manuals:
Service Manual
•
Publication Numbers:
47877014 (Jul 2015)
•
Language:
English
•
Format:
PDF

Description
Table of Contents
Content
Introduction
Engine
Hydraulics System
Frames and Ballasting
Tracks and Track Suspension
Cab Climate Control
Electrical System
Booms, dippers and buckets
Dozer Blade and Arm
Platform, cab, bodywork and decals
Special Tools Index
Hydraulic Schematics
Electrical Schematics
Manual Extract: Engine intake and exhaust system – Inspect
Suction air system inspection – functions The suction air system consists of an air cleaner, suction air line, and turbocharger or the like. Suction air enters the engine through the air cleaner and intake manifold.
Suction air system inspection
Inspection performed when there is a possibility that there is an abnormality in the suction air system
1. Inspect the air cleaner.
• There must be no excessive dirt or clogging.
2. If a problem is found, clean or replace.
3. Inspect the suction air line.
• There must be no crushing, breakage, or air leaks.
• There must be no inappropriate pipes or curves that would lead to increased suction air resistance.
• There must be no lead valve breakage.
4. If a problem is found, perform repair or replacement.
5. Inspect the turbocharger.
• There must be no abnormal rattling of the turbine shaft.
• There must be no oil leakage.
6. If a problem is found, perform repair or replacement.
