Case CX180C Crawler Excavator Service Manual Workshop Guide
Case CX180C Crawler Excavator Service Manual Workshop Guide
Regular price
$63.00 USD
Regular price
Sale price
$63.00 USD
Taxes included.
Shipping calculated at checkout.
Quantity
.
In Stock
Couldn't load pickup availability
Format : PDF
SUPPLIED AS DOWNLOADABLE LINK
Manual Included:
•
Service Manual:
3017 Pages & 2995 Pages
Specifications:
•
Brand:
New Holland
•
Model:
CX180C
•
Type:
Excavator
•
Manuals:
Service Manual
•
Publication Numbers:
48139070 (April 2017) and 48044245
•
Language:
English
•
Format:
PDF
Description
Table of Contents
Content
Introduction
Engine
Hydraulics System
Frames and Ballasting
Tracks and Track Suspension
Cab Climate Control
Electrical System
Booms, dippers and buckets
Platform, cab, bodywork and decals
Special Tools Index
Hydraulic Schematics
Electrical Schematics
Manual Extract: Boom regeneration
When the boom plunger is operated to the lower side, the plunger moves to the left, and the oil from the pump opens the load check valve and is fed to the cylinder rod side from the feed path.
The bottom side return oil opens the load holding valve poppet and flows through the back pressure check valve and into the tank path, but the pressure is boosted by the back pressure check valve. Part of it opens check valve A and is regenerated on the rod side and part of it opens check valve B and flows through the inside of the plunger and into the foot relief valve through the center bypass path to lower the pump flow.
