Case CX17C Mini Excavator Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
•
Service Manual:
1072 pages
Specifications:
•
Brand:
New Holland
•
Model:
CX17C
•
Type:
Mini Excavator
•
Manuals:
Service Manual
•
Publication Numbers:
48127447 (April 2017)
•
Language:
English
•
Format:
PDF

Description
Table of Contents
Content
Introduction
Engine
Hydraulics System
Frames and Ballasting
Tracks and Track Suspension
Electrical System
Booms, dippers and buckets
Dozer Blade and Arm
Platform, cab, bodywork and decals
Special Tools Index
Electrical Schematic
Hydraulic Schematic
Manual Extract: Camshaft alignment
1. Support the camshaft with V blocks on the surface plate at both end journals.
2. Set a dial indicator with its tip on the intermediate journal.
3. Measure the camshaft alignment.
4. If the measurement exceeds the allowable limit, replace the camshaft.
Camshaft alignment
Allowable limit: 0.01 mm (0.0004 in) SMIL17MEX0580AB 4
Cam height
1. Measure the height of the cam at its highest point with an outside micrometer.
2. If the measurement is less than the allowable limit, replace the camshaft.
Cam height (intake and exhaust) Factory specification: 26.88 mm (1.058 in) Allowable limit: 26.83 mm (1.056 in)
