Case CX145D SR Crawler Excavator Service Manual Workshop Guide
Case CX145D SR Crawler Excavator Service Manual Workshop Guide
Regular price
$66.00 USD
Regular price
Sale price
$66.00 USD
Taxes included.
Shipping calculated at checkout.
Quantity
.
In Stock
Couldn't load pickup availability
Format : PDF
SUPPLIED AS DOWNLOADABLE LINK
Manual Included:
•
Service Manual:
4446 Pages & 3656 Pages
Specifications:
•
Brand:
New Holland
•
Model:
CX145D SR
•
Type:
Excavator
•
Manuals:
Service Manual
•
Publication Numbers:
51458637 (Mar 2018) & 51458821
•
Language:
English
•
Format:
PDF
Description
Table of Contents
Content
Introduction
Engine
Hydraulics System
Frames and Ballasting
Tracks and Track Suspension
Cab Climate Control
Electrical System
Booms, dippers and buckets
Dozer Blade and Arm
Platform, cab, bodywork and decals
Special Tools Index
Hydraulic Schematics
Electrical Schematics
Manual Extract: Link between rear flange and spindle
1. Fit the O-rings (32) and (33) (2 pieces) into the O-ring grooves in spindle (2).
NOTE: when fitting the O-rings (32) and (33), do not apply grease to them.If they are reassembled with grease applied, the grease may ooze from the mating surface between rear flange (301) and spindle (2) while the travel motor is running. This may be mistaken for oil leakage; therefore, do not apply any grease.
2. Put 1.0 L (0.26 US gal) of hydraulic fluid in the spindle (2).
3. Aligning the parallel pins (34) (2 pieces) inserted in the spindle (2) with the pin holes in rear flange (301), fit the rear flange (301) into the spindle (2).
4. Temporarily tighten the hexagon socket head bolts (343) (10 pieces) to the spindle (2) with a hexagon wrench.
NOTE: make sure the hexagon socket head bolts (343) (10 pieces) are tightened evenly so that the rear flange may not be inclined, because the internal springs (113) will make it float gradually from the mating surface.
