Case 851 EX Backhoe Loader Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
•
Service Manual:
1008 pages
Specifications:
•
Brand:
Case
•
Model:
851 EX
•
Type:
Loader
•
Manuals:
Service Manual
•
Publication Numbers:
48190549 (Sep 2017)
•
Language:
English
•
Format:
PDF

Description
Table of Contents
Content
Introduction
Engine
Transmission
Front Axle
Rear Axle
Brakes and Controls
Hydraulic System
Frames and ballasting
Steering
Wheels
Cab climate control
Electrical System
Front Loader and Bucket
Platform, Cab, Bodywork and Decals
Special Tool Index
Manual Extract: Powered front axle – Disassemble
1. Remove the two double U-joints (6) from the axle beam (1).
2. Remove the seal rings (5) from the axle beam (1).
NOTE: Destructive operation for the seal rings (5), the seal rings must be replaced.
3. Remove the bush (4) from the axle beam (1) only if the wear conditions require this.
ATTENTION: Be careful not to damage the bush seat.
4. Remove the upper king pin bush (2) and the ball bearing cup (3) from the king pin seats using a suitable puller only if the wear conditions require this.
5. Remove the seal rings (7) from the axle beam (1).
NOTE: Destructive operation for the seal rings (7), the seal rings must be replaced.
6. Remove the bushes (8) from the axle beam (1) only if the wear conditions require this.
ATTENTION: Be careful not to damage the bush seats.
