Case 750L, 850L Crawler Dozer Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
•
Service Manual:
1516 pages
Specifications:
•
Brand:
New Holland
•
Model:
750L, 850L
•
Type:
Dozer
•
Manuals:
Service Manual
•
Publication Numbers:
87728445 (Mar 2008)
•
Language:
English
•
Format:
PDF

Description
Table of Contents
Introduction
Distribution Systems
Power Production
Power Train
Travelling
Body and Structure
Tool Positioning
Working Arm
Tools and Couples
Hydraulic Schematics
Electrical Schematics
Manual Extract: Relief valve Pressure setting
1. Remove the hex cap (3) and the spring (5) from the top of the circuit relief valve.
2. Remove the plunger (2) and inspect for damaged or worn parts or seals. Repair as necessary.
3. Add shims (4) to the plunger to increase the pressure setting. Remove shims (4) from the plunger to decrease the pressure setting. Each shim is 0.254 mm (0.010 in) thick and will change the pressure setting by 3.4 10.3
bar (50 150
psi).
4. Install the spring (5) and the hex cap (3) on the circuit relief valve.
5. Install the circuit relief valve into the equipment control valve and refer to Relief valve Pressure test
(A.12.A) to check the pressure setting.
6. Adjust the circuit relief valve again if necessary.
7. When the pressure setting is correct, remove the hand pump and connect the hydraulic line.
