Case 721F Wheel Loader Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
•
Service Manual:
2331 pages & 1020 pages
Specifications:
•
Brand:
Case
•
Model:
721F
•
Type:
Loader
•
Manuals:
Service Manual
•
Publication Numbers:
47881872 (June 2015) & 84488413 (April 2011)
•
Language:
English
•
Format:
PDF

Description
Table of Contents
Content
Introduction
Engine
Transmission
Four Wheel Drive System
Front Axle
Rear Axle
Hydraulic System
Frames and ballasting
Steering
Wheels
Cab climate control
Electrical System
Front Loader and Bucket
Platform, Cab, Bodywork and Decals
Special Tool Index
Manual Extract: Brake pump – Remove with fan pump
1. Remove and discard the bolts and straps that fasten the engine drive shaft to the transmission.
NOTICE: the bolts and straps that fasten the engine drive shaft to the transmission must be replaced when removed.
2. Loosen and remove the six bolts that fasten the engine drive shaft to the engine.
NOTE: the bolts that fasten the engine drive shaft to the engine must be replaced when removed.
3. Remove the engine drive shaft from the machine.
