Case 650M Crawler Dozer Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
•
Service Manual:
2046 pages
Specifications:
•
Brand:
New Holland
•
Model:
650M
•
Type:
Dozer
•
Manuals:
Service Manual
•
Publication Numbers:
48153338 (April 2018)
•
Language:
English
•
Format:
PDF

Description
Table of Contents
Contents
Introduction
Maintenance
Engine
Power Coupling
Hydrostatic Drive
Brakes and Controls
Hydraulic Systems
Hitches, drawbars and implement couplings
Tracks and Track Suspension
Cab Climate Control
Electrical System
Lubrication System
Dozer Blade and arm
Tools
Platform, cab, bodywork and decals
Specials Tool Index
Electrical Schematics
Hydraulics Schematics
Manual Extract: Fuel Prefilter
1. Open the right-hand side rear access door to locate the fuel prefilter cartridge (1).
2. Close the fuel shut off valve (2) to prevent fuel leakage.
3. Clean the outside of the fuel prefilter cartridge (1), fuel prefilter cartridge head (3) and remove any dirt and debris around the area that might contaminate the system.
4. Disconnect the wire harness (4) and remove the fuel prefilter cartridge (1).
5. Apply a thin layer of clean oil to the gasket on the new fuel prefilter cartridge (1).
6. Install and tighten the new fuel prefilter cartridge (1) by hand. Tighten the filter 1/2 to 3/4 turn after the filter cartridge gasket makes contact with the prefilter head (3).
7. Reconnect the wire harness (4).
8. Open the fuel shut off valve (2) and check for leaks.
