Case 586H, 588H Forklift Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
•
Service Manual:
1405 pages & 1604 pages
Specifications:
•
Brand:
Case
•
Model:
586H, 588H
•
Type:
Forklift
•
Manuals:
Service Manual
•
Publication Numbers:
47421773 (Aug 2012) & 47821916 (April 2015)
•
Language:
English
•
Format:
PDF

Description
Table of Contents
Introduction
Engine
Transmission
Front Axle
Rear Axle
Brakes and Controls
Hydraulic Systems
Frames and ballasting
Steering
Wheels
Electrical System
Telescopic single arm
Platform, cab, bodywork and decals
Special Tool Index
Electrical Schematic
Hydraulic Schematic
Manual Extract: Differential – Inspect
1. Clean all parts in cleaning solvent.
2. Inspect the bearing cup and the rollers in the bearings for flat areas, pitting, scoring, and other damage. Also check the inner race for damage. If any of these defects are found, a new bearing and bearing cup must be installed.
3. Inspect the teeth on the pinion gear and ring gear for pitting, scoring, and broken teeth. The ring gear and pinion gear must be replaced as a set.
4. Inspect the side gears, the pinion shaft, and the teeth of the pinion gears for pitting, scoring, and other damage.
Also inspect the thrust surfaces and the bore of each pinion gear. Check the splines in the side gears for wear. Use new parts as required.
5. Inspect the thrust washers for pitting, scoring, and other damage. Use new parts as required.
