Case 450, 550, 600 Quadtrac Tractor Service Manual Workshop Guide
Case 450, 550, 600 Quadtrac Tractor Service Manual Workshop Guide
Regular price
$75.00 USD
Regular price
Sale price
$75.00 USD
Taxes included.
Shipping calculated at checkout.
Quantity
.
In Stock
Couldn't load pickup availability
Format : PDF
SUPPLIED AS DOWNLOADABLE LINK
Manual Included:
•
Service Manual:
4883 pages
Specifications:
•
Brand:
Case
•
Model:
450, 550, 600 Quadtrac
•
Type:
Tractor
•
Manuals:
Service Manual
•
Publication Number:
47488212 (Feb 2013)
•
Language:
English
•
Format:
PDF
Description
Table of Contents
Contents
Introduction
Engine
Transmission
Rear Axle System
Power Take Off (PTO)
Brakes and Controls
Hydraulic System
Hitches, drawbars and implement couplings
Frames and ballasting
Steering
Wheels
Tracks and tract suspension
Cab Climate Control
Electrical Systems
Platform, Cab, bodywork and decals
Manual Extract: Powershift transmission – Pressure test – Solenoid swap test
It could be a sticking solenoid valve casing the transmission problems. For example, if the pressure reading was only low in gears 2, 7, 8 and 14, clutch 1M/solenoid Y is always engaged/energized in those gears.
Based on the ICU pressure readings, use the Engaged Clutch Pack table to determine which clutch is common to the low pressure readings. See Powershift transmission – General specification – Pressure test specifications and worksheets (21.113).
Thoroughly clean the range selector valve area before continuing.
1. Remove solenoid Y valve from the range selector
valve. Replace the Y solenoid with a new solenoid
valve. If a new solenoid valve is not available swap Y with another solenoid valve that is operating correctly.
2. Again drive the tractor in a clear and open area and record the transmission system pressures in each gear
both forward and reverse. Make note of shift quality in each gear.
If a new solenoid valve was installed and the transmission system pressure readings are consistent and shift quality has improved, troubleshooting is complete. If solenoid valves were swapped and the problem moves with the questionable solenoid, replace the questionable solenoid valve with a new solenoid valve. Troubleshooting is complete.
If the transmission system pressure readings are unchanged and the transmission shift quality remains poor, swap transmission solenoids back to original positions. Continue with the Transmission Clutch Pressure Test. See Powershift transmission – Pressure test (21.113).
