Case 1107EX Soil Compactor Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
•
Service Manual:
505 pages
Specifications:
•
Brand:
New Holland
•
Model:
1107EX
•
Type:
Compactor
•
Manuals:
Service Manual
•
Publication Numbers:
51478299 (May 2018)
•
Language:
English
•
Format:
PDF

Description
Table of Contents
Content
Introduction
Engine
Rear Axle System
Hydrostatic Drive
Brakes and Controls
Hydraulic System
Frames and Ballasting
Steering
Wheels
Cab Climate control
Electrical System
Platform, Cab, Bodywork and Decals
Special Tool Index
Manual Extract: Axle shaft – Replace – Short half shaft bushing
1. Disassemble the reduction gear group and the short half-shaft from the axle beam and remove the seal ring (3) from the axle beam (5).
NOTE: Replace the seal ring (3) if it is damaged.
2. Use a puller and remove the bush (4) from the axle beam (5).
3. Assemble the new bush (4) on the axle beam (5) using the suitable tool and a hammer.
4. Assemble the seal ring (4) to the axle beam (5) and check the correct position of the seal ring after the assembly.
