Case 1107DX Soil Compactor Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

Manual Included:
•
Service Manual:
623 pages
Specifications:
•
Brand:
New Holland
•
Model:
1107DX
•
Type:
Compactor
•
Manuals:
Service Manual
•
Publication Numbers:
47714442 (Oct 2014)
•
Language:
English
•
Format:
PDF

Description
Table of Contents
Content
Introduction
Engine
Rear Axle System
Hydrostatic Drive
Brakes and Controls
Hydraulic System
Frames and Ballasting
Steering
Wheels
Electrical System
Platform, Cab, Bodywork and Decals
Special Tool Index
Manual Extract: Valve drive and gears – Check
1. Disassemble the top engine assembly, refer to Engine and crankcase – Disassemble — Top Engine (10.001).
2. Disassemble the bottom engine assembly, refer to Engine and crankcase – Disassemble — Bottom Engine (10.001).
3. Check the intermediate gear for damage to its teeth 4. Replace the gear along with the bush bearing if it is damaged
5. Inspect intermediate gear bush internal diameter at two places and at right angles in pressed condition 6. If diameter exceeds the recommended limits replace the bush
7. Inspect the gear support journal diameter for wear with micrometer at two planes and at right angles 1
8. Replace gear support if it is damaged 9. Replace the washers
10. Replace the fasteners if it is damaged
