AGCO ST28A, ST33A Tractor Service Manual Workshop Guide

Format : PDF
SUPPLIED AS DOWNLOADABLE LINK

AGCO ST28A, ST33A Hydrostatic Tractor Manual : 226 Pages
AGCO ST28A, ST33A Standard Compact Tractor Manual : 246 Pages
Format: PDF
Book Number: 3378583M5
English
Issued October 2007

Description
AGCO ST28A, ST33A Tractor Manual
Service Manual for:
AGCO
Tractor
Format: PDF
Book Number: 3378583M5
English
Issued October 2007
AGCO ST28A, ST33A Hydrostatic Tractor Manual : 226 Pages
AGCO ST28A, ST33A Standard Compact Tractor Manual : 246 Pages
Manual TABLE OF CONTENTS
INTRODUCTION ……………………………………………………………………. 01
GENERAL INFORMATION …………………………………………………….. 02
DISASSEMBLY ………………………………………………………………………. 03
ENGINE ………………………………………………………………………………… 04A
ENGINE ACCESSORIES …………………………………………………………. 04B
CLUTCH ………………………………………………………………………………… 05
TRANSMISSION ………………………………………………………………………06
REAR TRANSMISSION …………………………………………………………… 07
REAR AXLE HOUSING …………………………………………………………….08
FRONT AXLE …………………………………………………………………………. 09
HYDRAULIC …………………………………………………………………………… 10
STEERING SYSTEM ………………………………………………………………… 11
ELECTRICAL ………………………………………………………………………….. 12
LUBRICATION AND MAINTENANCE ……………………………………… 13
ST28A, ST33A Manual Extract – REMOVE THE EXTERIOR PARTS AS A SET
The fender, frames, steeling post and fuel tank can be removed as a set if necessary.
Remove the front grille, hood and side covers with reference to 1. HOOD AND FRONT GRILLE.
Remove the column cover, rear cover and meter panel with reference to (14) to (17) of 2. SEAT, FENDERS, FLOOR DECK, AND RELATED PARTS.
Disconnect the throttle wire cable.
Disconnect and release the related wiring harness (with reference to WIRING HARNESS RAYOUT).
Remove the lowering speed control knob and the differential lock lever.
Remove the center cover.
Remove the sheet panel with the seat.
Remove the hydraulic control link assembly.
